Five major advantages of using alumina ceramic dry grinding material instead of high chromium steel balls for cement grinding.
① Energy saving and consumption reducing: With a loading capacity of 60% of steel balls, the current of the main machine of the mill is reduced by more than 20%; More than 15% of electricity is saved per ton of cement.
② Quality improvement: Improve grinding efficiency; Improve cement performance; More reasonable particle size distribution; Improved sphericity of particles; Cement has good adaptability to concrete admixtures.
③ Cooling and noise reduction: the temperature inside the mill is reduced by more than 20 ℃; Reduced mill noise.
④ Wear resistance: The ball wear of microcrystalline high-strength wear-resistant ceramic abrasive is 50% of that of steel balls.
⑤ Environmental Protection: The use of microcrystalline high-strength wear-resistant ceramic grinding bodies is beneficial for achieving green production.
Specification and model:mm
Diameter | Φ30 Φ25 Φ20 Φ19 Φ17 Φ15 Φ13 |
Dimension | 30±2 25±1.5 20±1.5 19±1 17±1 15±1 13±1 |
Comparison of Physical Properties between Alumina Ceramic Dry Grinding Bodies and High Chromium Steel Balls for Cement Grinding
Project | Density | Bulk density | Hardness | Fragmentation degree | Loss |
g/cm3 | t/m³ | Mohs | ‰ | g/Ton of cement | |
High chromium steel ball | 7.6-7.8 | 4.5 | 6.8 | <3 | <30 |
Alumina ceramic dry grinding body | 3.6-3.8 | 2.2 | 9.0 | <3 | <20 |
